Note: the condensing unit can be Thermo King and Carrier
SPECIFICATION
|
| Dimension(Lx W xH)（unloaded（mm） |
8995×2550×3450 |
| Body volume (m3) |
36 |
| Refrigerator Model |
THERMO KING T-600M (Independent) |
| Refrigerated Cargo Body Size: |
6800mm×2330mm×2400mm, with one bulkhead |
| Panel Thickness(mm) |
Roof and Floor panel |
105 mm |
| Side panels |
85 mm |
| Approaching angle/Departure angle（°） |
17/9 |
| Overhang(front/rear) (mm) |
1935/1800 |
| Wheel base (mm) |
5000 |
| Max speed（km/h） |
100 |
| Curb weight（kg） |
9400 |
| Engine |
Model |
ISDe21030 |
| Fuel type |
Diesel |
| Power, max（kw/rpm） |
210HP |
| Emission |
EURO 3 |
| Fuel tanker capacity（L） |
200L iron oil tank |
| Transmission |
Model |
8JS85T |
| Brake system |
Service brake |
Dual circuit compressed air brake |
| Parking brake |
spring energy, compressed air operating on rear wheels |
| Front axle |
4.8T |
| Rear axle |
10T |
| Tire |
295/80R22.5 |
| Electrical system |
Battery |
2X12V/165Ah |
| Alternator |
28V-1500kw |
| Starter |
7.5Kw/24V |
| Cab |
L3000 CAB |
More Details
Tags: cold chain truck, fruit refrigerated truck, refrigerated truck, refrigerated truck for fruit
